KX018-4

Compact Excavators

For Competitive Pricing
Refer to Dealer
Digging has never been easier than with the Kubota KX018-4 compact excavator. Combine the KX018-4’s 16.1 horsepower with superior maneuverability and versatility, and you’ll never worry about whether or not you can get the job done. Dig to your heart’s desire and do it comfortably, in the KX018-4’s spacious optional cab. There’s never been a better way to move ground. Read Disclaimer

Features & Details

Variable Width Undercarriage*

To enable passage through narrow spaces such as doorways and gates, the adjustable width track frame can be reduced by simply operating a single lever. Plus, changing the blade width is as easy as removing one pin by hand.

*Available on K008-3, K008-5, U10-5, KX018-4

Clean Running Kubota Tier 4 Engine

Kubota excavators are all powered by Kubota Tier 4 emission engines. The modern engine design maximizes digging and lifting performance, delivers minimized noise and vibration and meets the latest engine emission regulation.

Two Speed Travel

All Kubota excavators have a two speed drive that allows for efficient machine maneuverability and backfill operations.

Changeable Control Pattern

Convenient Two-pattern Selection System (TPSS) allows you to change between ISO and SAE operating patterns with a quick flip of the TPSS switch – without tools or leaving your seat.

Comfort & Convenience

  • A spacious operator station designed for greater comfort, with a fully flat floor for more legroom
  • Digital panel with easy access, simple settings and easy-to-read indicators and alerts
  • Easy cab entry and exit
  • Easy-open front slide window
  • Wrist rest
  • Cup holder
  • Optional cab

Serviceability

  • Front pin bushings to help maximize durability
  • Centralized swivel bearing lubrication
  • Protected cylinder hoses
  • Steel hood panels
  • One-sided engine maintenance
  • Wide hood openings for easy access to engine and other vital components

Auxiliary

  • Proportional flow control of auxiliary circuit (AUX1) and maximum oil flow setting – you can operate a larger variety of auxiliary attachments than ever before
  • Proportional AUX flow switch – a convenient bi-directional switch enables easy operation of hydraulic thumbs and other hydraulic attachments such as augers and breakers

SPECS & COMPARE: Kubota Models

KX018-4

16.1 HP. Superior maneuverability in a compact frame.

SEE DEALERSHIP FOR PRICE
  • Engine Model
    Kubota D902-BH-E4
  • Horsepower (gross)
    16.1
  • Displacement (cu. in.)
    54.80 (898)
  • Overall Length
    12ft 2.1in (3710)
  • Overall Height
    7ft 7.7in (2330) / 7ft 8.5in (2350)
  • Overall Width
    4ft 3.2in (1300) / 3ft 3.0in (990)
  • Min. Ground Clearance
    6.3in (160)
  • Crawler Length
    5ft 2.6in (1590)
  • Pump Capacity (GPM)
    4.6 (17.3) × 2 / 2.8 (10.4) × 1 / 1.7 (6.2) × 1
  • Auxiliary Hydraulics Flow Rate (GPM)
    7.4 (27.7)
  • Bucket Breakout Force (lbs.)
    3594 (1630)
  • Arm Breakout Force (lbs.)
    1852 (840)
  • Traveling Speed: High (mph)
    1.4 (2.2)
  • Traveling Speed: Low (mph)
    2.5 (4.0)
  • Ground Contact Pressure (psi)
    3.7 (0.26) / 3.8 (0.27)
  • Blade Width
    4ft 3.2in (1300) / 3ft 3.0in (990)
  • Blade Height
    9.1in (230)
  • Hydraulic Oil Reservoir / System
    4.1 (15.5) / 7.4 (28)
  • Fuel Reservoir
    5.6 (21)
  • Operating Weight lbs. (kg)
    3748 (1700) / 3968 (1800)
  • Build
  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •
§The Manufacturer's Suggested Retail Price excludes tax, dealer fees, and optional equipment. The equipment shown is for illustrative purposes only and may not be base equipment.

Add Ons


ea35_main

Excavator Auger

 Excavator Augers dig holes for footings or fences using the excavator's flexibility to access hard to reach areas or dig to greater depths than a compact track loader / skid steer loader.
