DM1024

Disc Mowers

For Competitive Pricing
Refer to Dealer
0 0 60 Offer Badge

Extended Warranty

Effective and reliable, the Kubota DM1024 Disc Mower brings you a working width of 7’ 9” and the confidence you’re looking for in a hay tool. A hydraulic cylinder easily lifts the disc mower without utilizing the three-point linkage and when you’re transporting it to and from the field it nimbly folds into a vertical position. Three, counter rotating discs make short work of your brush and the DM1024 only requires a minimum of 46 PTO horsepower to operate. Read Disclaimer

Features & Details

workingwidth

Available Working Widths

  • DM1017 – 5’6”
  • DM1022 – 7’2”
  • DM1024 – 7’9”
05_BreakAway

Spring Loaded Breakaway

When an obstacle is encountered, the DM1000 series swings backwards to protect the cutterbar; by reversing, the mower is reset into working position.

04_Fast-lifting-on-headlands

Fast Lift on Headlands

The mower is easily lifted via a hydraulic cylinder without activating the tractor’s 3-point linkage. This causes less wear on the tractor and the machine, as the PTO stays in the same position, minimizing vibrations in the transmission.

_DSC9897-copy

Vertical Transport Position

When in transport, the mowers are folded to a vertical position well behind the tractor. The center of gravity is close to the tractor, which ensures excellent weight distribution and transport stability.

01_triangular-discs

Counter-Rotating Three-Bladed Discs

With three blades per disc Kubota mowers are constantly cutting. This means a third less load per blade; an even load on the drive; smoother power usage; and produces an even, cleanly cut stubble.


SPECS & COMPARE: Kubota Models

DM1024

Just as effective as it is reliable.

SEE DEALERSHIP FOR PRICE
  • Cutting Width ft. (m)
    7' 9" (2.4)
  • Weight lbs. (kg)
    992 (450)
  • Transport Width ft. (m)
    3' 9" (1.2)
  • Hitch (CAT)
    2
  • Pin Hitch
    Not Available
  • PTO RPM
    540
  • Minimum PTO Horsepower Required HP/KW
    46/34
  • Number of Disc and Knives
    6/18
  • Remotes
    1
  • Cutterbar Operating Angle
    -45/+15
  • Stubble Height in. (mm)
    0.78"-1.97" (20-50)
  • BreakAway
    Standard
  • Non-Stop BreakAway
    N/A
  • Overrun Clutch
    Standard
  • Swath Board (RH/LH)
    Standard/Optional
  • Swath Rollers (RH/LH)
    Optional (RH)
  • High Skids +20/+40/+80 mm
    Optional
  • Lighting Kit
    Optional
  • Build
  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •
