LoopMe

TE4052T

Tedders

For Competitive Pricing
Refer to Dealer
0 0 60 Offer Badge

Extended Warranty

Kubota's TE4052T unique frame design ensures years and years of service. The four rotors with their wide flat tine arms and tines smoothly picks up the crop and evenly distributes it for ask even drying. Read Disclaimer

Features & Details

04_Strong-chassis-design

Strong Chassis Design

All Kubota tedders are built around a rugged, CNC bend, box chassis made out of one piece of metal with only one welding seam for maximum rigidity. The chassis design is fully enclosed at the top edge for maximum strength.

03_Super-C-Tine

Super-C Tine

The symmetric Kubota Super-C tines efficiently pick up the crop from two different areas. As it spreads the crop, the crop is inverted so the lower crop is placed on the top, giving a more even dry down. The crop is then spread evenly across the width of the machine for consistent drying. These tines are made of 0.39" shot-peened spring steel. Our spring coil diameter has a 20% larger diameter than conventional designs. This increases each tine service life, even when tedding heavy, high moisture crops.

0614_TedderGearBox_2810

Rotor Gearbox

These Kubota tedder models have a maintenance-free, oil-immersed gearbox, which means less time required for servicing and more time in the field. The gearboxes are integrated into the frame, making them extremely durable. Because they are not part of the frame structure, but are mounted within the actual frame, the gearbox is relieved of frame stresses.

_DSC0287-copy

Pull Type Version

Pull-type design with low weight and power requirements. The low weight of 904 lbs. is ideal for applications with small tractors, or in hilly terrain.


SPECS & COMPARE: Kubota Models

TE4052T

Rugged and dependable.

SEE DEALERSHIP FOR PRICE
  • Working Width ft. (m)
    17' 1" (5.2)
  • Tedding Width ft. (m)
    17' 9" (5.4)
  • Transport Width ft. (m)
    9' 6" (2.9)
  • Storage Height ft. (m)
    8' "8" (2.65)
  • Weight lbs. (kg)
    904 (410)
  • Linkage Drawbar
    Standard
  • Number of Rotors
    4
  • Number of Tine Arms/Rotors
    6
  • Tine Adjustment System
    Standard
  • Reduction Gearbox for Night Windrows
    Optional
  • Wheels (4)
    16x6.5-8
  • Wheels with Integrated Lighting
    Optional
  • Build
  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •

  •
